Signal and information processing for sensing systems

Santiago Marco Colás | Group Leader
Agustín Gutiérrez Gálvez | Senior Researcher
Raquel Cumeras Olmeda | Postdoctoral Researcher
Jordi Fonollosa Magrinyà | Postdoctoral Researcher
Silvia Mas Garcia | Postdoctoral Researcher
Jia Yan | Postdoctoral Researcher
Javier Burgués Calderón | PhD Student
Ana Maria Solórzano Soria | PhD Student
Lluís Fernández Romero | Laboratory Technician
Saeedeh Taghadomi-Saberi | Visiting Researcher


santi2015_1Current smart instrumentation using multi-sensors and/or spectrometers provides a wealth of data that requires sophisticated signal and data processing approaches in order to extract the hidden information.

Left: System to test chemical sensor arrays for diversity and redundancy

In this context, we are interested in intelligent chemical instruments for the detection of volatile compounds and smells.

These systems can be based on an array of nonspecific chemical sensors with a pattern recognition system , taking inspiration from the olfactory system. Some spectrometries, e.g. Ion Mobility Spectrometry, are capable of very fast analysis with good detection limits but poor selectivity. These technologies have been proposed for the fast determination of the volatolome (volatile fraction of the metabolome), instead of the reference technique of gas chromatography – mass spectrometry.

santi2015_2Our group develops algorithmic solutions for the automatic processing of Gas Sensor Array, Ion Mobility Spectrometry (IMS) and Gas Chromatography – Mass Spectrometry (GC-MS) data for metabolomics and food samples.

In a parallel activity, our group is working on the detection of drowsiness in drivers using vehicle dynamic measures.

Right: System to test chemical chemical sensors for malodour detection

Our research in 2016 included the following:

Signal and Data Processing for smart chemical Instrumentation:
1. We have studied calibration transfer methods among chemical sensor arrays to reduce calibration costs.
2. We have studied how to reduce the cross-sensitivity to humidity in chemical sensors
3. We have designed methodologies to estimate the limit of detection in chemical sensors inspired in the IUPAC recommendations.
4. We have been working in the detection of toxic emissions from fires to improve building occupant’s safety.
5. In collaboration with Universitat de Lleida (Dr. J. Palacin) and University of Örebro (Prof. A. Lilienthal) we are testing chemical source localization algorithms with autonomous robots.


Left: The SAFESENS project aims to produce personal health monitors for emergency personnel including toxic hazards detection
