Gallium (Ga) has been recently proposed as a novel therapeutic agent, since it promotes bone formation and exhibits antibacterial properties. This work focuses on the optimization of a thermochemical treatment that incorporates Ga ions by the addition of the body-friendly Ga nitrate approved by the Food and Drug Administration. The objective was to simultaneously provide the inner and the outer surfaces of porous‑titanium surfaces obtained by 3D-printing with bioactivity and antibacterial properties. The apatite-forming ability of the coating, as well as the antibacterial activity and SaOS-2 cell adhesion, proliferation, differentiation and mineralization were evaluated and compared with untreated Ti surfaces. The characterization of the surfaces revealed the presence of a Ga-containing calcium titanate layer, which was non cytotoxic and in simulated body fluid produced a homogeneous apatite coating well adhered to the substrate. The formation of this apatite layer was accelerated with increasing Ga amounts present on the surface, resulting also in an increase in thickness. An initial quick release of Ga ion promoted the antibacterial effect against gram positive strains, especially for Pseudomonas aeruginosa, one of the most frequent resistant pathogens in nosocomial infections. SaOS-2 cells adhered and proliferated on the Ga-doped Ti surfaces, its presence contributed to cell differentiation and to considerably increase the mineralization levels. Thus, the developed multifunctional coatings could provide bioactivity to the porous Ti implants while protecting them from the most frequent gram-negative pathogens.

JTD Keywords: 3D-printing, Antibacterial activity, Biomaterials, Gallium, Porous structures, Titanium implants

Titanium (Ti) and Ti alloys have been used for decades for bone prostheses due to its mechanical reliability and good biocompatibility. However, the high stiffness of Ti implants and the lack of bioactivity are pending issues that should be improved to minimize implant failure. The stress shielding effect, a result of the stiffness mismatch between titanium and bone, can be reduced by introducing a tailored structural porosity in the implant. In this work, porous titanium structures were produced by direct ink writing (DIW), using a new Ti ink formulation containing a thermosensitive hydrogel. A thermal treatment was optimized to ensure the complete elimination of the binder before the sintering process, in order to avoid contamination of the titanium structures. The samples were sintered in argon atmosphere at 1200 °C, 1300 °C or 1400 °C, resulting in total porosities ranging between 72.3% and 77.7%. A correlation was found between the total porosity and the elastic modulus of the scaffolds. The stiffness and yield strength were similar to those of cancellous bone. The functionalization of the scaffold surface with a cell adhesion fibronectin recombinant fragment resulted in enhanced adhesion and spreading of osteoblastic-like cells, together with increased alkaline phosphatase expression and mineralization.

JTD Keywords: Direct ink writing, Osseointegration, Recombinant protein, Thermoresponsive binder, Titanium, Titanium scaffold

Metallic implants have some limitations related to bioactivity and bacteria colonization leading to infections. In this regard, calcium phosphate coatings can be used as carrier for drug delivery in order to improve the mentioned drawbacks. The present work proposes the introduction of an antibacterial agent in the course of a pulsed and reverse pulsed electrodeposition. Calcium phosphate coatings were prepared in 30 min using different pulse waveforms (unipolar-bipolar), current densities (2–5 mA/cm2) and temperatures (40–60 °C). Mechanical stability of the as-coated surfaces was studied in order to select the optimal electrodeposition conditions. Subsequently, selected coatings were loaded with an antiseptic agent, chlorhexidine digluconate (CHX), via a single-step co-deposition procedure. CHX concentration added to the electrolyte was adjusted to 3 mM based on the antibacterial efficacy of the loaded coatings evaluated in vitro with Staphylococcus aureus and Escherichia coli bacteria strains. Whereas the same chlorhexidine concentration was added to the electrolyte, results showed that the amount of CHX loaded was different for each condition while release kinetics was maintained. The results of this work demonstrate that a pulsed co-deposition strategy has great potential to modulate local delivery of antibacterial agents such as chlorhexidine digluconate, which may prevent early phase infections of metallic implants after insertion.

JTD Keywords: Antibacterial agent, Calcium phosphate, Characterization, Coating, Pulse electrodeposition, Titanium
